Boosted Turbine Inlet 3″ O.D Stainless Steel V-Band KitSuit Boosted 4949 up to 6862 Dual V-Band Turbochargers
Brand: AEROFLOW
Part Number: AF8080-1016
Description:
These Boosted by Aeroflow range of V-Band kits are specifically designed for the range of Boosted turbochargers. Made from either 304 stainless steel or aluminium. These v-band may also suit other turbochargers please ensure to check all measurements provided.
Note: Molygrease all threads before installation and removal.
Material is 304 Stainless Steel.
Suits Boosted Turbocharger Turbine Inlet Flange.
Replacement V-band clamp isAF8080-3007.
AF8080-1016 Aeroflow Performance V-Band Suits Boosted Turbos below:
- AF8005-2010 / AF8005-2010BLK
- AF8005-2013 / AF8005-2013BLK
- AF8005-2015 / AF8005-2015BLK
- AF8005-2018 / AF8005-2018BLK
- AF8005-2022 / AF8005-2022BLK
- AF8005-2023 / AF8005-2023BLK
- AF8005-2025 / AF8005-2025BLK
- AF8005-2026 / AF8005-2026BLK
- AF8005-2027 / AF8005-2027BLK
- AF8005-3031 / AF8005-3031BLK
- AF8005-3032 / AF8005-3032BLK
- AF8005-3033 / AF8005-3033BLK
- AF8005-3034 / AF8005-3034BLK
- AF8005-4036 / AF8005-4036BLK
- AF8005-2110 / AF8005-2110BLK
- AF8005-2115 / AF8005-2115BLK
- AF8005-3101 / AF8005-3101BLK
- AF8005-3102 / AF8005-3102BLK
- AF8005-3106 / AF8005-3106BLK
- AF8005-3107 / AF8005-3107BLK
- AF8005-3116 / AF8005-3116BLK
- AF8005-3117 / AF8005-3117BLK
- AF8005-3125 / AF8005-3125BLK
- AF8005-3126 / AF8005-3126BLK
Suits Boosted Rear Housings below :
- AF8050-1000
- AF8050-1001
- AF8050-1005
- AF8050-1006
- AF8050-1007
- AF8050-1008
- AF8050-1015
- AF8050-1028
Additional Specifications:
Measurements of V-Band flange:
– V-Band Weld on Ferrule Inside Diameter – 56mm (2-13/64″).
– V-Band Weld on Ferrule Outside Diameter – 76.2mm (3″).
– V-Band Weld on Ferrule Lip Outside Diameter – 59.5mm (2-11/32″).
– Suits Exhaust Tube Outside Diameter – 63.5mm (2-1/2″).
